品名：30 Pin PCMCIA 公头组装式连接器
注：
1.材料：
1-1.触点：磷青铜
1-2.金属上盖：不锈钢
1-3.金属下盖：不锈钢
1-4.电缆：固定式：黄铜
1-5.外壳：尼龙46
1-6.塑料上盖：颜色见表A
1-7.塑料下盖：颜色见表A
1-8.SR：聚氯乙烯
2.电镀：
2-1.接触：见表A
2-2. 固定电缆：锡50u“
2-3.金属下料：镍60u“
品牌：科斯达开关KSDKG
产地：中国东莞
30 Pin PCMCIA 公头组装式连接器 是一种用于连接 PCMCIA 扩展卡的接口组件。PCMCIA（个人电脑内存卡国际协会）卡通常用于笔记本电脑和其他设备中以扩展功能或增加接口能力。以下是 30 Pin 公头组装式连接器的主要特点、应用以及安装与维护建议。
主要特征
1.引脚配置：
该连接器具有 30 个引脚，每个引脚有特定的功能（如数据传输、地线、供电等），以支持各种扩展卡的需求。
2.公头设计：
作为公头连接器，它可以很容易地插入到母头连接器或插槽中，形成坚固的电气连接。
3.组装式设计：
组装式的设计便于制造和维修，可以在需要时替换或更新连接器，适应不同的设计和功能需求。
4.材料与耐用性：
连接器通常采用高强度的塑料和金属材料，保证在各种工作环境中具备耐用性和可靠性。
应用领域
1.笔记本电脑：
在老旧型号的笔记本电脑中最为常见，用于连接网卡、存储卡、调制解调器等扩展功能。
2.嵌入式系统：
适用于嵌入式设备，以支持外部设备连接及功能扩展。
3.工业控制设备：
在工业自动化和控制系统中，作为通信和数据交换的连接接口。
安装与维护建议
1.焊接和安装：
在安装过程中，请确保按照规范进行焊接，并保障连接器正确安装，避免由于不当操作造成的损坏。
2.插拔注意事项：
插拔连接器时要轻柔，避免用力过猛，损坏引脚或连接器本身。
3.定期功能测试：
安装完成后，进行全面的功能测试，确保信号传输正常，连接稳定。
4.清洁和维护：
定期检查连接器及其周围环境，保持插槽及连接器的清洁，以防灰尘和污物影响连接性能。
总结
30 Pin PCMCIA 公头组装式连接器 是进行设备扩展和功能增强的重要组成部分，尤其是在老旧设备中仍然发挥着关键作用。尽管现代设备逐渐转向新型接口，PCMCIA 仍然在特定场景中是不可或缺的。如果你有进一步的问题或需要具体的技术参数，欢迎联系技术员！
Product Name: 30 Pin PCMCIA Male Assembled Connector
Note:
1. Materials:
1-1. Contact: phosphor bronze
1-2. Metal cover: stainless steel
1-3. Metal lower cover: stainless steel
1-4. Cable: Fixed type: Brass
1-5. Shell: Nylon 46
1-6. Plastic cover: color as shown in Table A
1-7. Plastic lower cover: color as shown in Table A
1-8.SR: Polyvinyl chloride
2. Electroplating:
2-1. Contact: See Table A
2-2. Fixed cable: Tin 50u“
2-3. Metal cutting: Nickel 60u“
Brand: Coaster Switch KSDKG
Origin: Dongguan, China
The 30 pin PCMCIA male connector is an interface component used to connect PCMCIA expansion cards. PCMCIA (Personal Computer Memory Card International Association) cards are commonly used in laptops and other devices to expand functionality or increase interface capabilities. The following are the main features, applications, and installation and maintenance recommendations of a 30 pin male connector assembly.
Main features
1. Pin configuration:
This connector has 30 pins, each with specific functions such as data transmission, grounding, power supply, etc., to support the needs of various expansion cards.
2. Public head design:
As a male connector, it can be easily inserted into a female connector or slot to form a sturdy electrical connection.
3. Modular design:
The modular design is convenient for manufacturing and maintenance, and connectors can be replaced or updated as needed to meet different design and functional requirements.
4. Materials and Durability:
Connectors are typically made of high-strength plastic and metal materials to ensure durability and reliability in various working environments.
application area
1. Laptop:
It is most common in older models of laptops, used for connecting network cards, storage cards, modems, and other extended functions.
2. Embedded systems:
Suitable for embedded devices to support external device connectivity and functional expansion.
3. Industrial control equipment:
In industrial automation and control systems, it serves as a connection interface for communication and data exchange.
Installation and maintenance recommendations
1. Welding and installation:
During the installation process, please ensure that welding is carried out according to the specifications and ensure that the connector is installed correctly to avoid damage caused by improper operation.
2. Precautions for plugging and unplugging:
When plugging and unplugging connectors, be gentle to avoid excessive force that may damage the pins or the connector itself.
3. Regular functional testing:
After installation, conduct a comprehensive functional test to ensure normal signal transmission and stable connection.
4. Cleaning and maintenance:
Regularly inspect the connectors and their surrounding environment, keep the slots and connectors clean to prevent dust and dirt from affecting the connection performance.
summary
The 30 pin PCMCIA male connector is an important component for device expansion and functional enhancement, especially in older devices where it still plays a critical role. Despite the gradual shift towards new interfaces in modern devices, PCMCIA remains indispensable in specific scenarios. If you have further questions or need specific technical parameters, please feel free to contact the technician!
