BTB连接器技术指标:
额定电流3.0AMP
接触电阻20mΩ Max
耐电压1000V AC/DC
绝缘电阻1000mΩ Min
工作温度﹣40℃ to +105℃
接触材料 Brass
接触镀层 Au Or Sn over Ni
绝缘材料 PA9T Black+30％GF UL94V-0 BK
品牌 科斯达 KOSOD KSDKG
BTB Connector Specifications:
Rated current 3.0AMP
Contact resistance 20mΩ Max
Withstand voltage 1000V AC/DC
Insulation resistance 1000mΩ Min
Operating temperature -40℃ to +105℃
Contact material Brass
Contact Plating Au Or Sn over Ni
Insulation material PA9T Black+30%GF UL94V-0 BK
Brand KOSOD KOSOD KSDKG
