KSD-DI-04F3-01

KSD-DI-04F3-01

  • 产品特性
  • 应用范围

图纸下载 样品申请

品名：Screw Lock Size 7系列DIN母头连接器
1.材料：
1-1. 外壳：尼龙66 UL94V-0；颜色：黑色
1-2.触点：磷青铜
1-3.外壳A：锌合金
1-4.外壳B：黄铜
1-5.0-RING A:NBR；颜色：黑色
1-6螺钉：合金钢
1-7.灯：黄铜
1-8.SR:TPR
2.完成：
2-1.触点A:10U“最小镀金
2-2.外壳A：整体镀镍60u”~100u”
2-3.外壳B：整体镀镍60u”~100u”
2-4.螺钉：整体镀镍60u”~100u”
3.电气规格：
3-1. 额定电流：1A
3-2.额定电压：交流30V，直流42V
4.环境：
4-1.工作温度：-25℃~85℃
品牌：科斯达开关KSDKG
产地：中国东莞


Screw Lock Size 7系列DIN母头连接器是一款广泛应用于电子和工业设备中的高性能连接器。该连接器采用螺丝锁定设计，确保连接的稳定性和可靠性，适用于需要安全和稳固连接的各种应用。

特点
1.螺丝锁定机制：
连接器通过螺丝固定的方式实现稳固连接，适合在震动或移动的环境中使用，避免因机械冲击导致的松动。

2.优质材料：
通常采用高强度金属和耐用塑料制造，具有良好的抗损性和耐用性。
引脚部分常常经过镀金或镀镍处理，以提高导电性和耐腐蚀性，确保长时间的稳定性能。

3.多种配置：
Size 7系列母头连接器提供多种引脚配置，以满足不同信号和功率传输的需求。
适用多种标准和规格，可以与多类型的DIN公头连接器兼容。

4.防护性能：
设计上具有防水和防尘功能，适用于工业环境、医疗设备和其他严格环境的需求。
可选配密封圈，以进一步增强其防护性能，确保连接的可靠性。

应用领域

1.音频与视频设备：
在专业音响和视频监控、广播设备中广泛应用，提供高质量的信号传输。

2.工业自动化：
用于工业控制系统、自动化机器、传感器等领域，确保设备间可靠的电气连接。

3.通信设备：
在网络和数据通信设备中被广泛使用，确保数据的稳定传输。

4.医疗设备：
由于其高可靠性和稳定的连接特性，非常适合医疗行业中的设备连接需求。

优势

1.连接安全性高：螺丝锁定机制能够确保连接的稳定性，适合要求高安全性的应用。

2.耐用性强：高质量的材料和工艺使得该连接器在多种环境中都能良好工作，具有较长的使用寿命。

3.灵活应用：可与多种设备和应用场景兼容，实现多样化的连接需求。

使用注意事项

1.确保正确安装：在连接时，确保引脚对齐，避免因强行连接造成损坏。

2.定期检查维护：定期检查连接器的外观和功能，确保没有污垢、腐蚀或损坏。

3.适度拧紧：在使用螺丝固定连接时，不要过度拧紧，避免损坏连接器或设备。

小结
Screw Lock Size 7系列DIN母头连接器因其稳定的锁定机制、优质的材质和多样的应用领域而备受青睐，成为许多行业中的重要连接解决方案。如果您对该系列连接器有进一步的需求或希望获取更多技术规格，欢迎联系技术员！



Product Name: Screw Lock Size 7 Series DIN Female Connector
1. Materials:
1-1.  Shell: Nylon 66 UL94V-0; Color: Black
1-2. Contact: phosphor bronze
1-3. Shell A: Zinc alloy
1-4. Shell B: Brass
1-5.0-RING A: NBR； Color: Black
1-6 screws: alloy steel
1-7. Lamp: Brass
1-8.SR: TPR
2. Complete:
2-1. Contact A: 10U "minimum gold plating
2-2. Shell A: Whole nickel plated 60u "~100u"
2-3. Shell B: Whole nickel plated 60u "~100u"
2-4. Screw: Whole nickel plated 60u "~100u"
3. Electrical specifications:
3-1.  Rated current: 1A
3-2. Rated voltage: AC 30V, DC 42V
4. Environment:
4-1. Working temperature:- 25℃~85℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China


The Screw Lock Size 7 series DIN female connector is a high-performance connector widely used in electronic and industrial equipment. This connector adopts a screw locking design to ensure the stability and reliability of the connection, suitable for various applications that require safe and stable connections.

characteristic
1. Screw locking mechanism:
The connector is securely connected by screws and is suitable for use in environments with vibration or movement, avoiding looseness caused by mechanical impact.

2. High quality materials:
Usually made of high-strength metal and durable plastic, it has good resistance to damage and durability.
The pin part is often treated with gold or nickel plating to improve conductivity and corrosion resistance, ensuring long-term stability.

3. Multiple configurations:
The Size 7 series female connector offers multiple pin configurations to meet the needs of different signal and power transmission.
Suitable for multiple standards and specifications, compatible with various types of DIN male connectors.

4. Protective performance:
Designed with waterproof and dustproof functions, suitable for industrial environments, medical equipment, and other strict environmental requirements.
Optional sealing rings are available to further enhance its protective performance and ensure the reliability of the connection.

application area

1. Audio and video equipment:
Widely used in professional audio and video surveillance, broadcasting equipment, providing high-quality signal transmission.

2. Industrial automation:
Used in industrial control systems, automation machines, sensors, and other fields to ensure reliable electrical connections between equipment.

3. Communication equipment:
Widely used in networks and data communication devices to ensure stable transmission of data.

4. Medical equipment:
Due to its high reliability and stable connection characteristics, it is very suitable for the device connection needs in the medical industry.

advantage

1. High connection security: The screw locking mechanism ensures the stability of the connection, making it suitable for applications that require high security.

2. Strong durability: High quality materials and processes enable the connector to work well in various environments and have a long service life.

3. Flexible application: It can be compatible with multiple devices and application scenarios, achieving diverse connectivity needs.

Precautions for use

1. Ensure correct installation: When connecting, make sure the pins are aligned to avoid damage caused by forced connections.

2. Regular inspection and maintenance: Regularly inspect the appearance and function of the connector to ensure that there is no dirt, corrosion, or damage.

3. Moderate tightening: When using screws to secure connections, do not overtighten to avoid damaging connectors or equipment.

Summary
The Screw Lock Size 7 series DIN female connectors are highly favored for their stable locking mechanism, high-quality materials, and diverse application areas, becoming an important connection solution in many industries. If you have further requirements for this series of connectors or would like to obtain more technical specifications, please feel free to contact a technician!
