技术指标:
工作电压: 50V AC/DC
额定电流: 0.5A AC/DC
耐电压: 500V AC/minute
接触电阻: 20mΩ max
绝缘电阻: 800mΩ min
工作温度: -25 to + 85°C
接触材料: phosphor bronze
接触镀层: tin plating over Ni
绝缘材料: LCP
包装:Reel
交货时间:7~15 Day
UL:Yes
ROHS Compliant
品牌 科斯达 KOSOD KSDKG
Technical indicators:
Working voltage: 50V AC/DC
Rated current: 0.5A AC/DC
Withstand voltage: 500V AC/minute
Contact Resistance: 20mΩ max
Insulation resistance: 800mΩ min
Operating temperature: -25 to + 85°C
Contact material: phosphor bronze
Contact Plating: tin plating over Ni
Insulation material: LCP
Packaging:Reel
Delivery time: 7~15 Days
UL: Yes
ROHS Compliant
Brand KOSOD KOSOD KSDKG
