广东科斯达科技股份有限公司
线数：2-30
额定电流：0.5A
额定电压：50V
耐电压：500V
接触电阻：≤30mΩ
绝缘电阻：500MΩ
工作温度：-20℃~+85℃
塑件(材质)：LCP, UL94V-0
插簧(材质)：黄铜，镀锡
焊片(材质)：磷青铜，镀锡
包装：2P/2K/卷装 3P以上 1.5K/卷
品牌 科斯达 KOSOD KSDKG
Number of lines: 2-30
Rated current: 0.5A
Rated voltage: 50V
Withstand voltage: 500V
Contact resistance: ≤30mΩ
Insulation resistance: 500MΩ
Working temperature: -20℃~+85℃
Plastic parts (material): LCP, UL94V-0
Insert spring (material): brass, tin plated
Solder Tab (Material): Phosphor Bronze, Tin Plating
Packing: 2P/2K/roll 3P or more 1.5K/roll
Brand KOSOD KOSOD KSDKG
