线数：02 ~ 16
接触电阻：≤20mΩ
绝缘电阻： ≥500MΩ
额定电压：125V AC DC
额定电流：1.OA AC DC
耐 电 压： 500V AC/minute
材 料：磷铜 LCP米色
温度范围：-25℃~+105℃
包装：1K/卷
品牌 科斯达 KOSOD KSDKG
Number of lines: 02 ~ 16
Contact resistance: ≤20mΩ
Insulation resistance: ≥500MΩ
Rated voltage: 125V AC DC
Rated current: 1.OA AC DC
Withstand voltage: 500V AC/minute
Material: Phosphor Bronze LCP Beige
Temperature range: -25℃~+105℃
Packing: 1K/roll
Brand KOSOD KOSOD KSDKG
