线数：2-16
额定电流：2.0A
额定电压：250V
耐电压：1000V
接触电阻：≤20mΩ
绝缘电阻：1000MΩ
工作温度：-25℃~+105℃
塑件(材质)：LCP, UL94V-0
插簧(材质)：黄铜，镀锡
焊片(材质)：磷青铜，镀锡
包装：600/卷
品牌 科斯达 KOSOD KSDKG
Number of lines: 2-16
Rated current: 2.0A
Rated voltage: 250V
Withstand voltage: 1000V
Contact resistance: ≤20mΩ
Insulation resistance: 1000MΩ
Working temperature: -25℃~+105℃
Plastic parts (material): LCP, UL94V-0
Insert spring (material): brass, tin plated
Solder Tab (Material): Phosphor Bronze, Tin Plating
Packing: 600/roll
Brand KOSOD KOSOD KSDKG
