WA-307

主要技术参数 Main Specifications

线 数（Poles）:02 to 12

接触电阻（Contact resistance):≤20m Ω

绝缘电阻（Insulation resistance):≥1000M Ω

额定电压（Rated voltage):250V AC DC

额定电流（Rated current):5.0A AC DC

耐 电 压（Withstand Voltage):1500V AC/minute

温度范围（Temperature Range):-45°C~+105°C

品牌 科斯达  KOSOD  KSDKG

Technical indicators:
Main Specifications

Lines (Poles): 02 to 12

Contact resistance: ≤20m Ω

Insulation resistance: ≥1000M Ω

Rated voltage: 250V AC DC

Rated current: 5.0A AC DC

Withstand Voltage: 1500V AC/minute

Temperature Range: -45°C~+105°C

Brand KOSOD KOSOD KSDKG
