技术指标:
额定电流: 9.0A
接触电阻: 10mΩ max
耐电压: 1500V AC/minute
绝缘电阻: 1000mΩ min
工作温度: -25 to + 85°C
接触材料: brass
接触镀层: Au or Sn over Ni
绝缘材料: LCP, NY6T, NY9T, PA66 + 30%GF
品牌 科斯达 KOSOD KSDKG
Technical indicators:
Rated current: 9.0A
Contact Resistance: 10mΩ max
Withstand voltage: 1500V AC/minute
Insulation resistance: 1000mΩ min
Operating temperature: -25 to + 85°C
Contact material: brass
Contact Plating: Au or Sn over Ni
Insulation material: LCP, NY6T, NY9T, PA66 + 30%GF
Brand KOSOD KOSOD KSDKG
