KSD-ZMS series 技术特性
标准规范
125伏交流电时为3A，12伏直流电时为3A
电气寿命：
0.01A 12V DC下100000次循环
在3A 12 V DC下进行100000次循环
6000次循环@3A 125 V交流电
绝缘电阻：最小100兆欧。
绝缘强度：500Vrms
工作温度：-40ºC至85ºC
品牌：科斯达开关 KSDKG/KOSOD SWITCH/KESIDA
科斯达开关厂的KSD-ZMS series、PCB 检测开关、通信设备和测试设备都有赖于科斯达开关 的耐久性、高响应 KSD-ZMS series系列微型微动开关。防水微动开关KSD-ZMS 系列具有可靠的速动机制和紧凑的尺寸, 而这紧凑的尺寸为设计师提供了额外的空间 — 并为其各种应用提供了所需的长电气和机械寿命。
Current Rating:100mA (DC)
Circuit:SPST-NO
Mounting Type:Chassis Mount
Sealing:Sealed - IP67
Illumination:No/None
Switch Function:Off-Mom On
Electrical Life Cycles:100,000
Voltage Rating - AC:
Voltage Rating - DC:12V
Actuator Type:Round (Pin Plunger)
Termination Style:Wire Leads
Additional Features:
Operating Force, Torque:130gf
Release Force:13gf
Pretravel:0.030" (0.8mm)
Differential Travel:0.012" (0.3mm)
Overtravel:0.065" (1.7mm)
Packaging:Bulk
