NZ-AC-102A-C3

NZ-AC-102A-C3

  • 产品特性
  • 应用范围

图纸下载 样品申请


钮子开关技术特性

1、规格:3A 125VAC1.5A 250VAC

2、接触电阻:小于20mΩ

3、絶缘电阻:500VDC不低于1000MΩ

4、耐电压:1000VAC1分钟

5、工作温度:-25℃~+85

6、电气寿命:10,000次以上

7、机械寿命:40,000次以上

材质

基座:PPAUL94V-0

手柄:黄铜,镀铬

轴套:黄铜,镀镍或镀铬

铁壳:不锈钢

支架:黄铜,镀锡

接触片/端子:铜合金,镀银或镀金



Toggle switch Rocker switch technical characteristics

1. Specifications: 3A 125VAC; 1.5A 250VAC

2. Contact resistance: less than 20mΩ

3. Insulation resistance: 500VDC not less than 1000MΩ

4. Withstand voltage: 1000VAC, 1 minute

5. Working temperature: -25℃~+85

6. Electrical life: more than 10,000 times

7. Mechanical life: more than 40,000 times

Material

Base: PPA (UL94V-0)

Handle: brass, chrome plated

Shaft sleeve: brass, nickel-plated or chrome-plated

Iron case: stainless steel

Bracket: brass, tin plated

Contact piece/terminal: copper alloy, silver-plated or gold-plated
