KSD-Y series 技术特性
标准规范
KSD-Y series 系列4, 5 & 6 钥匙开关
触点材料：4安培@125伏交流电或28伏直流电；2安培@250伏交流电（UL/CSA）。其他额定值见数据表
电气寿命：满载时10000次通断循环
接触电阻：典型值低于10毫欧。初始电压为2-4V DC，100mA，适用于镀银和镀金触点
绝缘电阻：最小109欧姆。
绝缘强度：海平面最低1000Vrms
索引：45º或90º，2-4个位置（4和5个制栓开关锁）。45º，3个位置；或90º，2个位置（6个转筒管状开关锁）
品牌：科斯达开关 KSDKG/KOSOD SWITCH/KESIDA
产品应用：医疗电器、航模、无人机、灯具照明、通讯、控制手柄、速控设备、新能源、航模设备、仪表仪器、小家电、汽车等领域
科斯达开关厂的KSD-Y series系列 4, 5 & 6 钥匙开关是一种防静电开关, 防止超过 20 KV 静电。高性能 Y 系列产品通常用于收款机、销售终端机和计算机, 有瞬时型号和带引线和/或线束。
KSD-Y series technical features
standard specification
KSD-Y series 4, 5&6 key switches
Contact material: 4 amperes @ 125 volts AC or 28 volts DC; 2 Amperes @ 250V AC (UL/CSA). Other rated values are shown in the data sheet
Electrical lifespan: 10000 on-off cycles at full load
Contact resistance: Typical value below 10 milliohms. Initial voltage is 2-4V DC, 100mA, suitable for silver and gold plated contacts
Insulation resistance: minimum 109 ohms.
Insulation strength: minimum 1000Vrms at sea level
Index: 45 º or 90 º, 2-4 positions (4 and 5 bolt switch locks). 45 º, 3 positions; Or 90 º, 2 positions (6 drum shaped switch locks)
Brand: Coaster Switch KSDKG/KOSOD SWITCH/KESIDA
Product applications: medical appliances, model aircraft, drones, lighting fixtures, communication, control handles, speed control equipment, new energy, model aircraft equipment, instrumentation, small appliances, automobiles and other fields
The KSD-Y series 4, 5&6 key switches from Costa Switch Factory are anti-static switches that prevent static electricity exceeding 20 KV. High performance Y series products are commonly used in cash registers, sales terminals, and computers, with instant models and with leads and/or wiring harnesses
