产品材质 1.Keystake NYLON
2.cover NYLON
3.Crochet Needle SUS
4.Base NYLON
5.Spring SUS Natural
6.Terminal Brass Plating silvering
7.Contact Phosphor Bronze Plating silvering
使用温度范围 -25℃ to +80℃
操作力 200±80gf
最大额定(电阻负载) 0.1A 30V DC
最小额定(电阻负载) 50μA 3V DC
电性能 耐电压 250V AC for 1 minute
绝缘电阻 100MΩ min. 500V DC
接触电阻(初期/寿命后) 100mΩ max. (Initial performance)
耐久性能 无负载寿命 100,000 cycles 100mΩ max.
负载寿命（最大额定负载）
10,000 cycles 100mΩ max.
