KSD-WP-05F2-91-11

KSD-WP-05F2-91-11

  • 产品特性
  • 应用范围

图纸下载 样品申请

品名：7  8 母头后锁式防水连接器-Crimp Type
1.材料：
1-1.住房：TPU；颜色：黑色
1-2.触点：黄铜
1-3.外壳：黄铜
1-4.O环：三元乙丙橡胶；颜色：黑色
1-5.螺母：黄铜
2.完成：
2-1.触点：整体镀金
2-2. 螺母：全部镀镍
2-3.外壳：全部镀镍
3.电气规格：
3-1.额定电流：20A
3-2.额定电压：250V
3-3.防水等级：IP68
4.环境：
4-1.工作温度：-40℃~105℃
品牌：科斯达开关KSDKG
产地：中国东莞


7母头和8母头后锁式防水连接器（Crimp Type）是一种常见的连接器类型，广泛应用于需要防水和稳定连接的电子设备中。以下是关于这种连接器的一些详细信息。

1. 特点
a. 后锁设计
安全锁定：后锁式设计能够在连接时提供额外的锁定机制，确保连接稳定，防止因振动或拉扯导致的松脱。
操作便捷：用户可以方便地插拔连接器，同时保持连接的牢固性。

b. 焊接类型（Crimp Type）
铆接连接：采用铆接（压接）方式将导线与连接器引脚连接，确保可靠的电气信号传输。
导电性能优良：压接点提供良好的电气接触，减少接触电阻，适于高电流和高频率应用。
适用范围广：可以与多种类型的电缆配合使用，适应不同的应用需求。

c. 防水性能
防护等级：连接器一般具有IP67或更高的防水等级，有效防止外界水分和尘埃的侵入。
密封设计：通常配备密封圈，确保连接器在潮湿或恶劣环境下的正常工作。

d. 多针孔配置
针脚数量：7针和8针的设计，可以传输多个信号或电源，同时满足复杂的电气连接需求。
可定制性：根据需要，连接器的引脚排列和配置可以进行定制，以适应具体的应用场景。

2. 应用领域
汽车和交通行业：在汽车电子系统中连接传感器、执行器、控制模块等，确保在各种气候条件下的可靠性。

工业自动化：在工厂设备、机器人等中，用于高频率信号和电源的稳定传输。

户外设备：如防水摄像头、LED照明系统及其他自主设备，防止水和灰尘的侵袭。

消费电子：在智能设备及其他电子产品中提供稳定可靠的连接。

3. 选择与使用注意事项
选择合适的导线型号：确保与连接器匹配的导线直径和类型，保证压接效果。

焊接/压接质量控制：压接时应确保连接牢固，避免接触点磨损或氧化造成的电气故障。

定期检查：定期检查连接器的密封性和连接状况，避免因损坏导致设备故障。

遵循安装指南：遵循制造商的技术文档和安装指南，确保正确安装和使用连接器。

4. 总结
7母头和8母头后锁式防水连接器（Crimp Type）是一种非常可靠的电气连接解决方案，能够在严苛环境中保持稳定性能。无论是在汽车、工业还是户外领域，这种连接器都能有效保护设备的电气连接。如果您需要更多具体信息或报价，欢迎联系技术员！



Product Name: 7-8 Female Rear Lock Waterproof Connector Cremp Type
1. Materials:
1-1. Housing: TPU； Color: Black
1-2. Contact: Brass
1-3. Shell: Brass
1-4. O-ring: EPDM rubber; Color: Black
1-5. Nut: Brass
2. Complete:
2-1. Contact: Whole gold plating
2-2.  Nut: All nickel plated
2-3. Shell: All nickel plated
3. Electrical specifications:
3-1. Rated current: 20A
3-2. Rated voltage: 250V
3-3. Waterproof grade: IP68
4. Environment:
4-1. Working temperature:- 40℃~105℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China


Crimp Type connectors with 7-head and 8-head rear locking are a common type of connector widely used in electronic devices that require waterproof and stable connections. Here are some detailed information about this connector.

1. Characteristics
a. Rear lock design
Security lock: The rear lock design provides an additional locking mechanism during connection, ensuring stable connection and preventing loosening due to vibration or pulling.
Convenient operation: Users can easily plug and unplug connectors while maintaining the firmness of the connection.

b. Welding Type (Crimp Type)
Riveted connection: The wire is connected to the connector pins using riveting (crimping) to ensure reliable electrical signal transmission.
Excellent conductivity: The crimping point provides good electrical contact, reduces contact resistance, and is suitable for high current and high-frequency applications.
Wide applicability: It can be used in conjunction with various types of cables to meet different application needs.

c. Waterproof performance
Protection level: Connectors generally have a waterproof rating of IP67 or higher, effectively preventing the intrusion of external moisture and dust.
Sealing design: Usually equipped with sealing rings to ensure the normal operation of connectors in humid or harsh environments.

d. Multi pinhole configuration
Pin count: Designed with 7 and 8 pins, it can transmit multiple signals or power sources while meeting complex electrical connection requirements.
Customizability: The pin arrangement and configuration of the connector can be customized according to specific application scenarios.

2. Application Fields
Automotive and transportation industries: Connect sensors, actuators, control modules, etc. in automotive electronic systems to ensure reliability under various weather conditions.

Industrial automation: used for stable transmission of high-frequency signals and power in factory equipment, robots, etc.

Outdoor equipment: such as waterproof cameras, LED lighting systems, and other autonomous devices to prevent water and dust invasion.

Consumer electronics: providing stable and reliable connections in smart devices and other electronic products.

3. Precautions for selection and use
Choose the appropriate wire model: Ensure that the wire diameter and type match the connector, and guarantee the crimping effect.

Welding/crimping quality control: During crimping, ensure that the connection is firm and avoid electrical faults caused by contact point wear or oxidation.

Regular inspection: Regularly check the sealing and connection condition of the connector to avoid equipment failure caused by damage.

Follow installation guidelines: Follow the manufacturer's technical documentation and installation guidelines to ensure proper installation and use of the connector.

4. Summary
The Crimp Type connectors with 7-pin and 8-pin rear locking are a highly reliable electrical connection solution that can maintain stable performance in harsh environments. Whether in the automotive, industrial, or outdoor fields, this connector can effectively protect the electrical connections of equipment. If you need more specific information or a quote, please feel free to contact the technician!
