品名：DIN M16 母头组装式防水连接器
1.材料：
1-1.外壳：尼龙UL94V0；颜色：黑色
1-2.触点：磷青铜
1-3.主体：锌合金
1-4.锁壳：黄铜
1-5.弹簧：不锈钢
1-6.隔离：聚氯乙烯
1-7.灯具：锌合金
1-8.灯体：锌合金
1-9.螺钉：SPCC
1-10.背部主体：黄铜
1-11. O型圈1：硅胶；颜色：红色
1-12.压盖：硅胶颜色：黑色
1-13.陆地笼：POM；颜色：白色
1-14.压盖螺母：铝合金
1-15.O型圈2：硅胶；颜色：黑色
2.完成：
2-1.触点：接触面积：镀金
焊接区域：锡
底板：镍
2-2.主体：镀镍
2-3.锁壳：镀镍
2-4.夹具：镀镍
2-5.夹具主体：镀镍
2-6.螺钉：镀镍
2-7.背部：镀镍
2-8.花生：镀镍
3.电气规格：
3-1.额定电流：5A
3-2.额定电压：250V
3-3.防水等级：IP67
4.环境：
4-1.0工作温度：-20℃~85℃
品牌：科斯达开关KSDKG
产地：中国东莞
DIN M16 母头组装式防水连接器是一种设计用于提供可靠电气连接的工业连接器，广泛应用于需要防水和防尘的环境中。以下是其主要特征和描述：
主要特征：
1.标准化设计：
符合DIN标准，确保其与其他DIN连接器系列的兼容性，有利于各种应用场景的无缝连接。
2.防水性能：
具备IP67或更高等级的防护能力，能够在潮湿和多尘的环境中有效防止水和灰尘的侵入，为设备提供额外的保护。
3.组装式结构：
连接器的组装设计使得用户可以根据实际需求进行组装，选择合适的导线和接头，灵活性高。
4.耐用材料：
通常采用高强度工程塑料或铝合金制造，具有优良的耐腐蚀性、抗震性和耐高温性，适合恶劣工作环境。
5.多种引脚配置：
提供从2针到19针不等的多种引脚排列，能够满足不同电气连接需求，灵活应对各种应用。
6.电气性能稳定：
精密的金属接触件设计，确保良好的电气接触，降低接触电阻，提高信号传输的可靠性。
7.安装简便：
采用螺旋或卡扣式锁定机制，简化了安装和拆卸过程，减少了设备维护的复杂性。
应用领域：
DIN M16 母头组装式防水连接器广泛应用于以下领域：
工业自动化设备
机械和机器人技术
通信设备
医疗仪器
交通运输设备
环境监测设备
总结：
DIN M16 母头组装式防水连接器凭借其优良的防水性能、耐用的材料以及灵活的组装设计，成为许多工业应用中的理想选择，能够保证在各种严苛环境下的安全和稳定的电气连接。如果您有更具体的应用需求或问题，请联系技术员！
Product Name: DIN M16 Female Assembled Waterproof Connector
1. Materials:
1-1. Shell: Nylon UL94V0; Color: Black
1-2. Contact: phosphor bronze
1-3. Main body: Zinc alloy
1-4. Lock shell: brass
1-5. Spring: Stainless steel
1-6. Isolation: Polyvinyl chloride
1-7. Lighting fixtures: Zinc alloy
1-8. Lamp body: Zinc alloy
1-9. Screw: SPCC
1-10. Back body: brass
1-11. O-ring 1: Silicone; Color: Red
1-12. Cap: Silicone Color: Black
1-13. Land Cage: POM； Color: White
1-14. Cap Nut: Aluminum Alloy
1-15. O-ring 2: Silicone; Color: Black
2. Complete:
2-1. Contact: Contact area: Gold plating
Welding area: Tin
Bottom plate: Nickel
2-2. Main body: Nickel plated
2-3. Lock shell: Nickel plated
2-4. Fixture: Nickel plating
2-5. Fixture body: Nickel plated
2-6. Screw: Nickel plated
2-7. Back: Nickel plating
2-8. Peanuts: Nickel plating
3. Electrical specifications:
3-1. Rated current: 5A
3-2. Rated voltage: 250V
3-3. Waterproof grade: IP67
4. Environment:
4-1.0 Operating temperature:- 20℃~85℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China
DIN M16 female assembled waterproof connector is an industrial connector designed to provide reliable electrical connections, widely used in environments that require waterproofing and dust prevention. The following are its main features and descriptions:
Main features:
1. Standardized design:
Compliant with DIN standards, ensuring compatibility with other DIN connector series, facilitating seamless connections in various application scenarios.
2. Waterproof performance:
Equipped with IP67 or higher protection level, it can effectively prevent water and dust from entering in humid and dusty environments, providing additional protection for equipment.
3. Assembled structure:
The assembly design of connectors allows users to assemble according to their actual needs, select suitable wires and connectors, and has high flexibility.
4. Durable materials:
It is usually made of high-strength engineering plastics or aluminum alloys, which have excellent corrosion resistance, earthquake resistance, and high temperature resistance, and are suitable for harsh working environments.
5. Multiple pin configurations:
Provide a variety of pin arrangements ranging from 2 to 19 pins, which can meet different electrical connection needs and flexibly respond to various applications.
6. Stable electrical performance:
Precise metal contact design ensures good electrical contact, reduces contact resistance, and improves the reliability of signal transmission.
7. Easy installation:
Adopting a spiral or snap on locking mechanism simplifies the installation and disassembly process and reduces the complexity of equipment maintenance.
Application areas:
DIN M16 female assembled waterproof connectors are widely used in the following fields:
Industrial automation equipment
Mechanical and Robotics Technology
Communication equipment
Medical equipment
Transportation equipment
Environmental monitoring equipment
Summary:
The DIN M16 female assembled waterproof connector, with its excellent waterproof performance, durable materials, and flexible assembly design, has become an ideal choice for many industrial applications, ensuring safe and stable electrical connections in various harsh environments. If you have more specific application requirements or questions, please contact the technician!
