产品料号 | CEN65系列 |
额定负荷 | DC5V 1mA |
接触阻抗 | 5ΩMax |
绝缘阻抗 | 50MΩMin DC50V |
耐电压 | AC50V(50-60HZ)for1Minute |
电气寿命 | 100，000Cycles |
脉冲数 | 12Plus/360° |
扭矩 | 10-25gf.cm |
制动数 | 12 |
机械寿命 | 100，000Cycles |
使用温度 | -25℃+80℃ |
耐候性能 | | |
耐寒性 | -20℃ | 96H |
耐热性 | 80℃ | 96H |
耐湿性 | 60℃±2℃ | 90~95%RH 48H |
包装规格 | |
包装数(PCS) | 1盒 | 1000PCS |
| 1箱 | 10000PCS |
波峰自动焊接条件 | | |
项目 | 预热温度 | 100±10℃ |
预热时间 | 60S(max.) |
焊接温度 | 260±5℃ |
焊接时间 | 5±1S |
手工焊接条件 | | |
| 焊接温度 | 300℃±10℃ |
| 焊接时间 | 3+1/0S |
| 烙铁功率 | 60W(max.) |
注意事项： |
1.本产品目录中产品的颜色与实物的颜色有所差异 |
2.请以最小订购单位的N(整数）倍来订货 |
3.汽车用时，请进行确认后使用 |
