品名：M24 公头线端成型式防水连接器
1.材料
1-1.外壳：PBT UL94V-0；颜色：黑色
1-2.触点：黄铜
1-3. 螺母：黄铜
2.完成：
2-1.触点：金闪光微英寸
底板：镍
2-2. 螺母：镀镍。
3.电气规格：
3-1.额定电流：7.5A和25A
3-2.额定电压：125V和500V
3-3.防水等级：IPX7
4.环境：
4-1.工作温度：-40℃~85℃
品牌：科斯达开关KSDKG
产地：中国东莞


M24 公头线端成型式防水连接器概述
M24 公头线端成型式防水连接器是一种广泛使用的电气连接器，特别适用于需要防水、防尘特性的行业。此类连接器通常用于工业自动化、交通运输、通信、发电和其他需要稳定电气连接的应用中。M24 连接器因其较大的线径和多样的接线方式而广受欢迎，能够承载较大的电流，并提供优良的机械和电气性能。

主要特点
1.防水设计：
高防护等级：M24 连接器通常具有 IP67 或更高的防护等级，能有效抵御水和灰尘的侵入，确保在潮湿或恶劣环境下的可靠运行。
密封材料：连接器内部采用优质橡胶或硅胶密封圈，能够在连接时提供紧密的密封。

2.线端成型：
便捷连接：公头线端成型设计使得连接更加牢固和简便，标准化的设计减少了连接器间的差异，提高了互换性。
多种接线方式：支持多种线规和接线方式，包括螺孔、焊接等，适用于不同的接线需求。

3.耐用性：
优质材料：采用高强度塑料和金属材料，具备耐磨、抗腐蚀、抗冲击能力，确保持久使用。
抗震动设计：M24 连接器设计专注于抗震动和冲击，适合高震动环境。

4.多种配置：
可提供不同针脚数（如 2、3、4、5、7、12等），支持各种电气功能需求。

5.适用范围广：
可用于多个行业，如工业设备、汽车电子、医疗设备、通讯设备等。

应用领域
1.工业自动化：用于传感器、执行器、控制面板等设备的电气连接，能够抵御工业环境中的潮湿和尘埃。

2.交通设施：在车辆照明、导航系统和电控设备中应用，通过其坚固的防护确保安全稳定运行。

3.户外设备：用于户外照明、监控系统和其他需要可靠连接的设备，防止水和灰尘的入侵。

4.新能源：在太阳能、风能等可再生能源设备中，提供可靠的电气连接，适应不同环境条件。

使用注意事项
1.安装前检查：在连接前检查连接器的密封状态和插头是否完整，防止连接不良。

2.定期维护：确保连接器的清洁，防止污垢积累影响性能。

3.正确连接：确保按照制造商的说明正确连接线端，以防止损坏或短路。

4.温度和电流限制：在额定范围内使用，避免由于过载而导致连接器损坏。

总结
M24 公头线端成型式防水连接器是一种高性能、耐用且防护性能卓越的连接解决方案。通过其防水和防尘特性，它能确保在各种严苛环境下的稳定运行。这使得该连接器在许多行业中成为可靠电气连接的首选。如果您需要更多的技术支持、产品选择或咨询服务，欢迎联系技术员！



Product Name: M24 Male Wire End Forming Waterproof Connector
1. Materials
1-1. Shell: PBT UL94V-0； Color: Black
1-2. Contact: Brass
1-3.  Nut: Brass
2. Complete:
2-1. Contact: Gold Flash Micro inch
Bottom plate: Nickel
2-2.  Nut: Nickel plated.
3. Electrical specifications:
3-1. Rated current: 7.5A and 25A
3-2. Rated voltage: 125V and 500V
3-3. Waterproof grade: IPX7
4. Environment:
4-1. Working temperature:- 40℃~85℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China


Overview of M24 Male Wire End Forming Waterproof Connector
M24 male wire end molded waterproof connector is a widely used electrical connector, especially suitable for industries that require waterproof and dustproof characteristics. This type of connector is commonly used in industrial automation, transportation, communication, power generation, and other applications that require stable electrical connections. The M24 connector is widely popular due to its large wire diameter and diverse wiring methods, which can carry large currents and provide excellent mechanical and electrical performance.

main features
1. Waterproof design:
High protection level: M24 connectors typically have an IP67 or higher protection level, which can effectively resist the intrusion of water and dust, ensuring reliable operation in humid or harsh environments.
Sealing material: High quality rubber or silicone sealing rings are used inside the connector to provide a tight seal during connection.

2. End forming:
Convenient connection: The molded design of the male wire end makes the connection more secure and convenient, and the standardized design reduces the differences between connectors, improving interchangeability.
Multiple wiring methods: Supports multiple wire gauges and wiring methods, including screw holes, welding, etc., suitable for different wiring needs.

3. Durability:
High quality materials: Made of high-strength plastic and metal materials, with wear resistance, corrosion resistance, and impact resistance, ensuring long-lasting use.
Anti vibration design: M24 connector design focuses on anti vibration and impact, suitable for high vibration environments.

4. Multiple configurations:
It can provide different pin numbers (such as 2, 3, 4, 5, 7, 12, etc.) to support various electrical function requirements.

5. Wide applicability:
Can be used in multiple industries, such as industrial equipment, automotive electronics, medical equipment, communication equipment, etc.

application area
1. Industrial automation: used for electrical connections of sensors, actuators, control panels, and other equipment, capable of withstanding humidity and dust in industrial environments.

2. Transportation facilities: Applied in vehicle lighting, navigation systems, and electronic control equipment, ensuring safe and stable operation through their sturdy protection.

3. Outdoor equipment: used for outdoor lighting, monitoring systems, and other devices that require reliable connections to prevent the intrusion of water and dust.

4. New energy: Provide reliable electrical connections in renewable energy equipment such as solar and wind power to adapt to different environmental conditions.

Precautions for use
1. Pre installation inspection: Check the sealing status of the connector and whether the plug is complete before connection to prevent poor connection.

2. Regular maintenance: Ensure the cleanliness of the connector and prevent dirt accumulation from affecting performance.

3. Correct connection: Ensure that the wire ends are connected correctly according to the manufacturer's instructions to prevent damage or short circuits.

4. Temperature and current limitations: Use within the rated range to avoid connector damage due to overload.

summary
The M24 male end molded waterproof connector is a high-performance, durable, and highly protective connection solution. Through its waterproof and dustproof properties, it can ensure stable operation in various harsh environments. This makes the connector the preferred choice for reliable electrical connections in many industries. If you need more technical support, product selection, or consulting services, please feel free to contact a technician!
