船型开关 技术参数
1、功能：开-关-开
2、额定值：UE：250VAC 1/2HP 8A 250VAC 10A 125VAC
质量控制：6A/12A 250VAC
ENEC VDE：12A125VAC 6(4)A 250VAC。 T105
3、操作力：650350g.f
4、接触电阻：≤50 mn5、绝缘电阻：≥100 MO6、介电强度：
终端按钮 3000VAC/5mA/1 分钟终端。 到终端1500VAC/5mA/1分钟
ROCKER SWITCH TECHNICAL PARAMETERS
1、FUNCTION:ON-OFF-ON
2、RATING:UE: 250VAC 1/2HP 8A 250VAC 10A 125VAC
cQc: 6A/12A 250VAC
ENEC VDE:12A125VAC 6(4)A 250VAC . T105
3、OPERATION FORCE:650350g.f
4、CONTACT RESISTANCE:≤50 mn5、INSULATION RESISTANCE:≥100 MO6、DIELECTRIC WITHSTAND:
TEMINALTO BUTTON 3000VAC/5mA/1MINTUETERMINAL. TO TERMINAL1500VAC/5mA/1MINTUE
