船型开关 技术参数
1、功能：关-（开） 关-（开）
2、额定值：UL:16A 250VAC 1/4HP 20A 125VAC1/4HP 250VAC 3/4HP
ENEC VDE/cQc:16(4)A 250VAC T105
3.操作力：650士350g。 F
4、接触电阻：≤50 Mn5、绝缘电阻：2100 Mn
8、介电支架：端子至按钮 3000vAC/5mA/1MINTUE。
端子对端子 1500VAC/5mA/1 分钟。
ROCKER SWITCH TECHNICAL PARAMETERS
1、FUNCTION: OFF-(ON)
oFF-(oN)
2、RATING: UL:16A 250VAC 1/4HP 20A 125VAC1/4HP 250VAC 3/4HP
ENEC VDE/cQc:16(4)A 250VAC T105
3.OPERATION FORCE:650士350g. f
4、CONTACT RESISTANCE: ≤50 mn5、INSULATION RESISTANCE: 2100 Mn
8、DIELECTRIC WTHSTAND: TERMINAL TO BUTTON 3000vAC/5mA/1MINTUE.
TERMINAL TO TERMINAL1500VAC/5mA/1MINTUE.
