品名：M5 公头防水连接器
1.材料：
1-1.外壳：PBT UL94V-0；颜色：黑色
1-2.触点：黄铜
1-3.螺母：黄铜
1-4.外壳：黄铜
1-5.O型圈：NBR；颜色：黑色
2.完成：
2-1.触点：见表A
2-2. 螺母：镀镍
2-3.外壳：镀镍
3.电气规格：
3-1.额定电流：1A
3-2.额定电压：60V
3-3.防水等级：IP67
4.环境：
4-1.工作温度：-20℃~85℃
品牌：科斯达开关KSDKG
产地：中国东莞
M5 公头防水连接器
M5 公头防水连接器 是一种常用于工业和自动化领域的紧凑型连接器，因其小巧的尺寸和出色的防护性能而广泛应用。这种连接器提供了可靠的电气连接，能够在恶劣环境中工作，通常用于传感器、执行器和其他电子设备的连接。
主要特点
1.防水防尘设计：
IP67/IP68 防护等级：有效防止水和灰尘的侵入，确保在潮湿或尘土飞扬的环境中正常工作。
密封结构：采用密封圈和特殊材料，增强连接器的防护性能。
2.紧凑型设计：
小巧轻便：M5 连接器具有较小的直径，适合空间受限的应用场合。
易于安装：由于尺寸小，可以方便地安装在各种设备和电路板上。
3.高可靠性：
耐用的材料：使用高强度塑料和金属材料，确保连接器在高温、低温和其他极端环境下的稳定性。
抗震性能：设计上考虑了震动和冲击的影响，有效降低连接器因机械应力而产生的故障率。
4.多种类型及配置：
接线方式：可以选择焊接、螺旋或插头连接等多种接线方式，满足不同应用需求。
引脚数量：不同型号的 M5 公头连接器可提供 2 PIN、3 PIN、4 PIN 等多种引脚配置，以支持不同信号和电源需求。
5.广泛的兼容性：
标准化接口：M5 连接器符合国际标准，能够与其他品牌的连接器互换使用。
兼容性广：可与各种传感器、执行器、PLC 和其他控制设备实现无缝连接。
应用领域
1.工业自动化：广泛应用于传感器、执行器、控制器和其他自动化设备中。
2.机器人技术：在工业机器人、自动化设备中作为关键连接部件使用。
3.运输系统：用于轨道交通、智能交通和物流设备中。
4.环境监测：适用于气象监测、土壤监测等设备，确保可靠的数据传输。
5.消费电子：可用于智能家居设备和便携式电子产品。
使用注意事项
1.安装时检查密封性：确保密封圈无损伤，以保持其防水性能。
2.避免过载：遵循连接器的额定电压和电流，避免过载使用导致连接器损坏。
3.定期维护：定期检查连接器的连接状态，确保其性能和安全性。
4.防化学品侵蚀：尽量避免连接器接触强腐蚀性化学品，以延长其使用寿命。
总结
M5 公头防水连接器 是一款高性能、耐用且防护性强的连接器，适用于各种工业和户外环境。其设计紧凑、易于安装的特点，使其广泛应用于自动化、机器人和环境监测等领域。如果您需要更多信息或有任何疑问，欢迎联系技术员！
Product Name: M5 Male Waterproof Connector
1. Materials:
1-1. Shell: PBT UL94V-0； Color: Black
1-2. Contact: Brass
1-3. Nut: Brass
1-4. Shell: Brass
1-5. O-ring: NBR； Color: Black
2. Complete:
2-1. Contact: See Table A
2-2. Nut: Nickel plated
2-3. Shell: Nickel plated
3. Electrical specifications:
3-1. Rated current: 1A
3-2. Rated voltage: 60V
3-3. Waterproof grade: IP67
4. Environment:
4-1. Working temperature:- 20℃~85℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China
M5 male waterproof connector
M5 male waterproof connector is a compact connector commonly used in the industrial and automation fields, widely used due to its small size and excellent protective performance. This type of connector provides reliable electrical connections and can operate in harsh environments, typically used for connecting sensors, actuators, and other electronic devices.
main features
1. Waterproof and dustproof design:
IP67/IP68 protection level: effectively prevents the intrusion of water and dust, ensuring normal operation in damp or dusty environments.
Sealing structure: using sealing rings and special materials to enhance the protective performance of the connector.
2. Compact design:
Compact and lightweight: The M5 connector has a smaller diameter, making it suitable for applications with limited space.
Easy to install: Due to its small size, it can be easily installed on various devices and circuit boards.
3. High reliability:
Durable materials: Use high-strength plastic and metal materials to ensure the stability of the connector in high temperature, low temperature, and other extreme environments.
Seismic performance: The design takes into account the effects of vibration and impact, effectively reducing the failure rate of connectors caused by mechanical stress.
4. Multiple types and configurations:
Wiring method: Multiple wiring methods such as welding, spiral or plug connection can be selected to meet different application needs.
Pin quantity: Different models of M5 male connectors can provide various pin configurations such as 2 PIN, 3 PIN, 4 PIN, etc. to support different signal and power requirements.
5. Wide compatibility:
Standardized interface: M5 connectors comply with international standards and can be interchanged with connectors from other brands.
Wide compatibility: It can seamlessly connect with various sensors, actuators, PLCs, and other control devices.
application area
1. Industrial automation: widely used in sensors, actuators, controllers, and other automation equipment.
2. Robotics technology: used as a key connecting component in industrial robots and automation equipment.
3. Transportation system: used in rail transit, intelligent transportation, and logistics equipment.
4. Environmental monitoring: Suitable for meteorological monitoring, soil monitoring and other equipment to ensure reliable data transmission.
5. Consumer electronics: can be used for smart home devices and portable electronic products.
Precautions for use
1. Check the sealing during installation: Ensure that the sealing ring is not damaged to maintain its waterproof performance.
2. Avoid overload: Follow the rated voltage and current of the connector to avoid overloading and damage to the connector.
3. Regular maintenance: Regularly check the connection status of the connector to ensure its performance and safety.
4. Chemical corrosion prevention: Try to avoid connectors coming into contact with highly corrosive chemicals to extend their service life.
summary
The M5 male waterproof connector is a high-performance, durable, and highly protective connector suitable for various industrial and outdoor environments. Its compact design and easy installation make it widely used in fields such as automation, robotics, and environmental monitoring. If you need more information or have any questions, please feel free to contact the technician!
