品名：圆形防水连接器Quick Lock NY-LF10 防水系列公头
1.材料：
1-1. 外壳：PPS UL94V-0；颜色：黑色
1-2.触点：黄铜
1-3.插头外壳：锌合金
1-4. 锁环：锌合金
1-5.弹簧1：不锈钢
1-6.弹簧2：不锈钢
1-7.O型圈1：EPDM
1-8.背壳：锌合金
1-9.屏蔽：磷青铜
1-10.O型圈2：EPDM
1-11.灯具：黄铜
1-12.O型圈3：NBR；颜色：黑色
1-13.STRAIN减压环：尼龙66 UL94V-0；颜色：白色
1-14.拧紧套环：PPS；颜色：棕色
2.完成：
2-1.触点：金色闪光
2-2.接线片外壳：镍
2-3. 锁环：镍
2-4.后壳：镍
2-5.屏蔽：镍
2-6.灯具：镍
3.电气规格：
3-1.额定电流：3PIN 5A；6PIN 2A
3-2.额定电压：3PIN 125V AC / 175V DC；
6PIN 30V DC / 42V DC
3-3. 防水等级：IP67
4.环境：
4-1.工作温度：-25℃~85℃
品牌：科斯达开关KSDKG
产地：中国东莞
圆形防水连接器 Quick Lock NY-LF10 公头概述
Quick Lock NY-LF10 公头是专业设计的圆形防水连接器，属于防水系列，特别适用于各种对连接可靠性和防水性能要求较高的电气应用。该连接器广泛应用于工业、汽车、户外设备等领域，其卓越的性能和便捷的操作方式，使其成为理想的解决方案。
主要特点
1.快速连接设计：
便捷插拔：Quick Lock 机制使得连接器能够快速地插入和拔出，适合需要频繁更换或维护的应用。
稳定的锁定功能：连接后能够确保牢固和安全，防止在振动或冲击环境下意外断开。
2.卓越的防水性能：
高防护等级：NY-LF10 公头通常具有IP67或更高的防护等级，确保在潮湿和多尘环境中仍能安全工作。
优质密封设计：采用高性能密封材料（例如硅胶密封圈），有效防止水和灰尘进入连接器内部。
3.耐用性与可靠性：
高强度材料：该连接器使用耐高温、耐腐蚀的塑料和金属材料制造，适合恶劣环境下使用。
抗震动和冲击能力：强化设计让连接器在振动和冲击中仍能保持良好的连接状态。
4.多样化引脚配置：
灵活配置：根据需求提供不同引脚数量和排列，便于满足各种电气连接需求。
应用领域
1.汽车工业：用于电控单元、传感器、照明系统等关键应用。
2.工业自动化：广泛应用于机器人、PLC、传感器、马达控制等领域。
3.户外设备：适用于各种防水照明、监控设备等。
4.航空航天和军事：满足高可靠性和耐用性的需求，适合极端环境中使用。
使用注意事项
1.连接前的清洁：确保连接器和插头表面无污垢，保持干燥，以确保良好的电气接触。
2.定期检查密封：检查密封圈和防水性能，以防老化或磨损导致漏水。
3.合规使用：在连接器的额定电压和电流范围内使用，以避免损坏和故障。
4.遵循连接方向：按照设计方向正确插拔连接器，避免引脚弯曲或损坏。
总结
Quick Lock NY-LF10 防水系列公头连接器以其优异的防水性能和快速连接特性，在众多行业中得到了广泛应用。无论是在汽车、工业还是户外环境中，NY-LF10 都能提供稳定、安全的电气连接。如果您需要更多技术细节或购买建议，欢迎联系技术员！
Product Name: Circular Waterproof Connector Quick Lock NY-LF10 Waterproof Series Male Head
1. Materials:
1-1. Shell: PPS UL94V-0； Color: Black
1-2. Contact: Brass
1-3. Plug housing: Zinc alloy
1-4. Lock ring: Zinc alloy
1-5. Spring 1: Stainless steel
1-6. Spring 2: Stainless steel
1-7. O-ring 1: EPDM
1-8. Backshell: Zinc alloy
1-9. Shielding: phosphor bronze
1-10 O-ring 2: EPDM
1-11. Lamp: Brass
1-12. O-ring 3: NBR； Color: Black
1-13. STRAIN pressure reducing ring: Nylon 66 UL94V-0; Color: White
1-14. Tighten the collar: PPS； Color: Brown
2. Complete:
2-1. Contact: Gold Flash
2-2. Terminal block housing: Nickel
2-3. Lock ring: Nickel
2-4. Rear shell: Nickel
2-5. Shielding: Nickel
2-6. Lamp: Nickel
3. Electrical specifications:
3-1. Rated current: 3PIN 5A; 6PIN 2A
3-2. Rated voltage: 3PIN 125V AC/175V DC;
6PIN 30V DC / 42V DC
3-3. Waterproof grade: IP67
4. Environment:
4-1. Working temperature:- 25℃~85℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China
Overview of Quick Lock NY-LF10 Male Circular Waterproof Connector
Quick Lock NY-LF10 male connector is a professionally designed circular waterproof connector, belonging to the waterproof series, especially suitable for various electrical applications that require high connection reliability and waterproof performance. This connector is widely used in industries, automobiles, outdoor equipment, and other fields. Its excellent performance and convenient operation make it an ideal solution.
main features
1. Quick connection design:
Convenient insertion and removal: The Quick Lock mechanism enables connectors to be quickly inserted and removed, making it suitable for applications that require frequent replacement or maintenance.
Stable locking function: After connection, it can ensure firmness and safety, preventing accidental disconnection in vibration or impact environments.
2. Excellent waterproof performance:
High protection level: NY-LF10 male connectors typically have an IP67 or higher protection level, ensuring safe operation in humid and dusty environments.
High quality sealing design: using high-performance sealing materials (such as silicone sealing rings) to effectively prevent water and dust from entering the interior of the connector.
3. Durability and reliability:
High strength materials: This connector is made of high temperature resistant and corrosion-resistant plastic and metal materials, suitable for use in harsh environments.
Anti vibration and impact capability: The reinforced design ensures that the connector can maintain a good connection state even under vibration and impact.
4. Diversified pin configurations:
Flexible configuration: Provide different pin numbers and arrangements according to requirements to meet various electrical connection needs.
application area
1. Automotive industry: used for key applications such as electronic control units, sensors, lighting systems, etc.
2. Industrial automation: widely used in robots PLC、 Fields such as sensors and motor control.
3. Outdoor equipment: Suitable for various waterproof lighting, monitoring equipment, etc.
4. Aerospace and military: Meet the needs of high reliability and durability, suitable for use in extreme environments.
Precautions for use
1. Cleaning before connection: Ensure that the surface of the connector and plug is free of dirt and kept dry to ensure good electrical contact.
2. Regular inspection of sealing: Check the sealing ring and waterproof performance to prevent aging or wear that may cause water leakage.
3. Compliant use: Use within the rated voltage and current range of the connector to avoid damage and malfunction.
4. Follow the connection direction: correctly plug and unplug the connector according to the design direction to avoid pin bending or damage.
summary
The Quick Lock NY-LF10 waterproof series male connector has been widely used in many industries due to its excellent waterproof performance and fast connection characteristics. Whether in automotive, industrial, or outdoor environments, NY-LF10 can provide stable and safe electrical connections. If you need more technical details or purchasing advice, please feel free to contact the technician!
