品名：圆形防水连接器Quick Lock NY-LF10 防水系列母头
1.材料：
1-1. 外壳：PPS UL94V-0；颜色：黑色
1-2.触点：黄铜
1-3.插头外壳：锌合金
1-4. 锁环：锌合金
1-5.弹簧1：不锈钢
1-6.弹簧2：不锈钢
1-7.O型圈1：EPDM
1-8.背壳：锌合金
1-9.屏蔽：磷青铜
1-10.O型圈2：EPDM
1-11.灯具：黄铜
1-12.O型圈3：NBR；颜色：黑色
1-13.STRAIN减压环：尼龙66 UL94V-0；颜色：白色
1-14.拧紧套环：PPS；颜色：棕色
2.完成：
2-1.触点：金色闪光
2-2.接线片外壳：镍
2-3. 锁环：镍
2-4.后壳：镍
2-5.屏蔽：镍
2-6.灯具：镍
3.电气规格：
3-1.额定电流：3PIN 5A；6PIN 2A
3-2.额定电压：3PIN 125V AC / 175V DC；
6PIN 30V DC / 42V DC
3-3. 防水等级：IP67
4.环境：
4-1.工作温度：-25℃~85℃
品牌：科斯达开关KSDKG
产地：中国东莞
圆形防水连接器 Quick Lock NY-LF10 防水系列母头概述
Quick Lock NY-LF10 母头是专为需求高性能及防水保护的电气连接而设计的圆形防水连接器。在各种严苛环境下，它能够提供稳定的电气连接，广泛应用于工业、汽车、户外设备等领域。其快速连接设计和出色的密封性能，使得NY-LF10母头特别适合要求频繁连接和断开的应用场合。
主要特点
1.快速连接设计：
简易插拔：Quick Lock 机制使得连接器能够快速且方便地插入和拔出，极大地简化了安装和维护。
稳固锁定：锁定机制确保连接后不会轻易断开，提升使用安全性。
2.出色的防水性能：
高防护等级：NY-LF10母头通常具备IP67或更高的防护等级，有效防止水和灰尘的侵入，适用于潮湿和多尘的环境。
高质量密封设计：采用优质密封材料（如硅胶密封圈），保持内部连接稳定。
3.耐用性与可靠性：
强韧材料：由耐腐蚀、耐高温的塑料和金属材料制成，确保在恶劣工作条件下的可靠性。
抗震动设计：可承受高频震动和冲击，确保长期稳定使用。
4.多种引脚配置：
灵活选择：根据不同应用需求，NY-LF10 母头提供多种引脚数和布局选项，满足各种电气连接需求。
应用领域
1.汽车行业：广泛应用于电控系统、传感器、照明和其他电气组件。
2.工业自动化：在机器人技术、PLC控制、传感器接入和电机驱动等领域中有广泛应用。
3.户外设备：适用于安防监控、户外照明和其他需要防水性能的设备。
4.航空航天与军事：满足高可靠性和耐用性的连接需求，确保在极端条件下的正常运作。
使用注意事项
1.连接前的检查：确保母头和公头连接器的插头表面清洁无损，保持干燥，以确保良好连接。
2.定期维护：定期检查密封环状态，以确保防水性能不受老化或磨损影响。
3.符合规格使用：在连接器的额定电压和电流范围内使用，以避免损坏。
4.正确插入和拔出：遵循设计方向进行连接，避免引脚变形或损坏。
总结
Quick Lock NY-LF10 防水系列母头圆形连接器的设计旨在提供高效、安全和耐用的电气连接解决方案。凭借其卓越的防水性能、快速连接功能和坚固的材料，这款连接器成为多个行业中不可或缺的组成部分。如果您需要更多的技术信息或购买建议，欢迎联系技术员！
Product Name: Circular Waterproof Connector Quick Lock NY-LF10 Waterproof Series Female Head
1. Materials:
1-1. Shell: PPS UL94V-0； Color: Black
1-2. Contact: Brass
1-3. Plug housing: Zinc alloy
1-4. Lock ring: Zinc alloy
1-5. Spring 1: Stainless steel
1-6. Spring 2: Stainless steel
1-7. O-ring 1: EPDM
1-8. Backshell: Zinc alloy
1-9. Shielding: phosphor bronze
1-10 O-ring 2: EPDM
1-11. Lamp: Brass
1-12. O-ring 3: NBR； Color: Black
1-13. STRAIN pressure reducing ring: Nylon 66 UL94V-0; Color: White
1-14. Tighten the collar: PPS； Color: Brown
2. Complete:
2-1. Contact: Gold Flash
2-2. Terminal block housing: Nickel
2-3. Lock ring: Nickel
2-4. Rear shell: Nickel
2-5. Shielding: Nickel
2-6. Lamp: Nickel
3. Electrical specifications:
3-1. Rated current: 3PIN 5A; 6PIN 2A
3-2. Rated voltage: 3PIN 125V AC/175V DC;
6PIN 30V DC / 42V DC
3-3. Waterproof grade: IP67
4. Environment:
4-1. Working temperature:- 25℃~85℃
Brand: Coaster Switch KSDKG
Origin: Dongguan, China
Circular Waterproof Connector Quick Lock NY-LF10 Waterproof Series Female Head Overview
Quick Lock NY-LF10 female connector is a circular waterproof connector designed specifically for electrical connections that require high performance and waterproof protection. In various harsh environments, it can provide stable electrical connections and is widely used in industries, automobiles, outdoor equipment, and other fields. Its fast connection design and excellent sealing performance make the NY-LF10 female head particularly suitable for applications that require frequent connections and disconnections.
main features
1. Quick connection design:
Easy to plug and unplug: The Quick Lock mechanism enables connectors to be quickly and conveniently inserted and removed, greatly simplifying installation and maintenance.
Stable locking: The locking mechanism ensures that the connection will not be easily disconnected, improving usage security.
2. Excellent waterproof performance:
High protection level: The NY-LF10 female head typically has an IP67 or higher protection level, effectively preventing the intrusion of water and dust, and is suitable for humid and dusty environments.
High quality sealing design: using high-quality sealing materials (such as silicone sealing rings) to maintain stable internal connections.
3. Durability and reliability:
Strong and tough materials: made of corrosion-resistant and high-temperature resistant plastic and metal materials, ensuring reliability under harsh working conditions.
Anti vibration design: capable of withstanding high-frequency vibrations and impacts, ensuring long-term stable use.
4. Multiple pin configurations:
Flexible selection: According to different application requirements, the NY-LF10 female head provides multiple pin numbers and layout options to meet various electrical connection needs.
application area
1. Automotive industry: widely used in electronic control systems, sensors, lighting, and other electrical components.
2. Industrial automation: It is widely used in fields such as robotics, PLC control, sensor access, and motor drive.
3. Outdoor equipment: Suitable for security monitoring, outdoor lighting, and other devices that require waterproof performance.
4. Aerospace and military: Meet the connection requirements of high reliability and durability, ensuring normal operation under extreme conditions.
Precautions for use
1. Pre connection inspection: Ensure that the plug surfaces of the female and male connectors are clean and undamaged, kept dry, to ensure a good connection.
2. Regular maintenance: Regularly check the condition of the sealing ring to ensure that its waterproof performance is not affected by aging or wear.
3. Compliant with specifications: Use within the rated voltage and current range of the connector to avoid damage.
4. Correct insertion and extraction: Connect according to the design direction to avoid pin deformation or damage.
summary
The design of the Quick Lock NY-LF10 waterproof series female round connector aims to provide an efficient, safe, and durable electrical connection solution. With its excellent waterproof performance, fast connection function, and sturdy materials, this connector has become an indispensable component in multiple industries. If you need more technical information or purchasing advice, please feel free to contact the technician!
